ZHENGZHOU SHENGHONG HEAVY INDUSTRY TECHNOLOGY CO., LTD. Profil Perusahaan
Produk
Rumah > Produk > Lini produksi pupuk organik > Low-Temperature Crystallization Protection Fertilizer Granulator Line with Anti-Corrosive Hardened Alloy Rollers and No Drying Process Required
Low-Temperature Crystallization Protection Fertilizer Granulator Line with Anti-Corrosive Hardened Alloy Rollers and No Drying Process Required
Low-Temperature Crystallization Protection Fertilizer Granulator Line with Anti-Corrosive Hardened Alloy Rollers and No Drying Process Required

Low-Temperature Crystallization Protection Fertilizer Granulator Line with Anti-Corrosive Hardened Alloy Rollers and No Drying Process Required

Rincian produk

Tempat asal: Zhegzhou, Provinsi Henan Cina

Nama merek: Shenghong

Sertifikasi: SGS, ISO, BV

Nomor model: Seri SDZ

Syarat Pembayaran & Pengiriman

Kuantitas min Order: 1 set

Harga: can be negotiated

Kemasan rincian: Wadah atau kotak kayu lapis

Waktu pengiriman: 10-15 hari Ex-kerja

Syarat-syarat pembayaran: L/C,T/T

Menyediakan kemampuan: 200 set per bulan

Dapatkan Harga Terbaik

Rincian produk

Deskripsi Produk
Rincian produk
Menyoroti:
Kapasitas Produksi:
1 - 20 ton per jam
Masa garansi:
12 Bulan
Asal:
Zhengzhou Tiongkok
Konsumsi Energi:
Konsumsi Energi Rendah
Aduk bahan gigi:
Baja Mangan
Produk akhir:
Pelet pupuk majemuk NPK
Motor:
Sesuai dengan permintaan Anda
Tipe material:
baja tahan karat dan baja karbon
Kapasitas Produksi:
1 - 20 ton per jam
Masa garansi:
12 Bulan
Asal:
Zhengzhou Tiongkok
Konsumsi Energi:
Konsumsi Energi Rendah
Aduk bahan gigi:
Baja Mangan
Produk akhir:
Pelet pupuk majemuk NPK
Motor:
Sesuai dengan permintaan Anda
Tipe material:
baja tahan karat dan baja karbon
Deskripsi Produk
Rare Earth and Ammonium Bicarbonate Fertilizer Granulator Line
Product Introduction:
As a professional fertilizer machinery manufacturer, we supply the turnkey Rare Earth and Ammonium Bicarbonate Fertilizer Granulator Line to meet the growing global demand for processing specialized and heat-sensitive chemical formulas. Utilizing advanced dry compaction technology, this high-efficiency compound fertilizer line transforms raw ammonium bicarbonate powders and rare earth elements into high-density, uniform granules without adding water or chemical binders. Equipped with a heavy-duty ammonium bicarbonate granulator and rare earth fertilizer machine, this system operates entirely at low temperatures, ensuring zero decomposition of sensitive active nutrients while maximizing your factory ROI.
Rare Earth and Ammonium Bicarbonate Fertilizer Granulator Line overview
Key Performance Features
  • Low-Temperature Crystallization Protection: Designed specifically for heat sensitive material granulation, this line uses cool-press technology to prevent ammonium bicarbonate from decomposing or volatilizing during processing.
  • Anti-Corrosive Hardened Alloy Rollers: The ammonium bicarbonate granulator features heavy-duty alloy rollers designed to withstand chemical reactions and wear from complex chemical elements.
  • No Drying Process Required: Operating as a true non-drying system, this production line works efficiently with raw materials under 5% moisture content, bypassing the need for high-temperature dryers and lowering energy consumption.
  • High One-Time Molding Rate: The advanced double-roller extrusion mechanism ensures a granulation rate of over 90%, directly outputting robust, non-caking finished granules in a single pass.
Technical Specifications
Production Capacity 1 - 3 Tons/Hour (Customizable based on specialized formula requirements)
Granulation Method Double-Roller Dry Extrusion Compaction & Low-Temperature Flaking
Target Raw Materials Ammonium bicarbonate powder, rare earth fertilizer mixtures, urea, ammonium sulfate, and potash formulations
Finished Granule Size 2mm - 6mm Ball, Tablet, or Oblong shapes (Adjustable based on international market demand)
Roller Sheet Material High-strength wear-resistant manganese alloy or anti-corrosive stainless steel
Fertilizer granulator line working process
The 8-Stage Step-by-Step Working Principle
The entire process flow of this rare earth fertilizer machine and compound fertilizer line is scientifically laid out to guarantee continuous, automated, and trouble-free operation:
  1. Smart Raw Material Batching: The automated dosing and batching system precisely weighs ammonium bicarbonate powder, rare earth elements, and other compound ingredients according to your commercial formula ratios.
  2. Homogeneous Material Mixing: Industrial vertical or horizontal mixers blend the dry raw materials uniformly to improve the overall nutrient balance and fertilizer consistency of the final product.
  3. Double-Roller Extrusion Granulation: The core machine—the heavy-duty ammonium bicarbonate granulator—forces the raw powder through two counter-rotating rollers under high hydraulic pressure. The powder is instantly compacted into solid flakes at room temperature and then mechanical crushed into raw granules.
  4. Particle Drying (Energy-Saving Option): For special custom formulas requiring ultra-low moisture storage, granules can pass through a rotary dryer. *Note: For standard ammonium bicarbonate and heat sensitive material granulation, this high-temperature step is completely bypassed to prevent nutrient loss and save fuel costs.
  5. High-Efficiency Particle Cooling: Hot fertilizer particles from the extrusion phase are cooled in a rotary cooling machine to eliminate thermal stress and caking, preparing them for immediate packaging.
  6. Precision Particle Classification & Screening: A heavy-duty rotary screening machine grades the cooled fertilizer particles. Qualified products (2-4mm) move to the coating stage, while oversized and undersized dust are automatically returned via belt conveyor for re-compaction, ensuring 100% material utilization with zero waste.
  7. Finished Product Coating: Qualified granules enter the rotary coating drum, where an anti-caking agent or protective coating is applied to increase the brightness, roundness, and shelf-life of the commercial product in humid climates.
  8. Automated Weighing & Packaging: The final film-coated particles are automatically weighed, packed into 25kg or 50kg bags, and sealed, ready for direct market distribution or warehouse storage.
Get a Free Heat Sensitive Material Granulation Line Layout Design:
Are you looking for a reliable fertilizer plant manufacturer? Tell our engineering experts your raw materials and target hourly capacity. We will provide a customized factory blueprint and wholesale price quote within 24 hours! Inquire now for factory direct pricing.
